Service 04 / Milimetar 3D
Mechanical technical drawings
We turn a 3D model, sketch, measurements or an existing part into clear 2D technical documentation for production and communication.
Send your project
A drawing that communicates intent clearly.
A mechanical drawing connects an idea or 3D model with production, inspection and everyone involved in the project.
We define the scope around its purpose: the necessary views, sections, dimensions, tolerances and notes are prepared from the information you provide and the agreed requirements.
- Starting point3D model, sketch, measurements or an existing part
- ContentsViews, sections, dimensions and agreed notes
- PurposeProduction, inspection, quoting or internal documentation
- DeliveryPDF and an agreed CAD format
